2023
Honda
FourTrax Rancher
Stock #1260
MSRP: $5,899 USD
‹
›
Reset Zoom
X
‹
›
-
+
‹
›
This vehicle is getting attention.
157 people have recently viewed it.
Check Availability
Hi, my name is
and I'm interested in this
2023 Honda FourTrax Rancher Base
. I'm in the
area and you can reach me at
or on my
Mobile
Home
Work
phone at
.
Text
Email
Phone
Is this unit still available?
What payment terms are available?
Can I test ride this unit?
Questions / Comments
VehicleId
SubscriptionId
SubscriberId
Year
ModelName
MakeDivision
ProductTypeId
StyleName
ReturnURL
ModelNumber
Check Availability
Details
Status:
New
Vehicle:
2023 Honda FourTrax Rancher
VIN:
1HFTE390XP4901260
Model Number:
TRX420TM1P
Color:
Red
Stock Number:
1260
Title:
Clear
Location:
Champion Motorsports
Warranty:
Manufacturer's w/ Extended Available
Specifications
BRAKES
Front Brake Diameter (in):
7.5
Front Brake Diameter (mm):
190
Front Brake Type:
Dual Hydraulic Disc
Rear Brake Diameter (in):
6.3
Rear Brake Diameter (mm):
160
Rear Brake Type:
Sealed Drum
DRIVE LINE
Driveline Type:
4X2
Number Of Driveline Modes:
1
ENGINE
Bore (in):
3.41
Bore (mm):
86.5
Carburetion Brand:
Keihin
Carburetion Type:
Fuel Injected
Compression Ratio:
9.9
Cooling:
Liquid
Cylinders:
1
Displacement (cc):
420
Displacement (ci):
25.6
Engine Stroke:
4-Stroke
Engine Type:
Single-Cylinder
Fuel Injector Size (mm):
34
Fuel Injector:
Yes
Fuel Requirements:
Regular
Fuel Type:
Gas
Starter:
Electric
Stroke (in):
2.82
Stroke (mm):
71.5
Valve Configuration:
OHV
Valves Per Cylinder:
2
Valves:
2
EXTERIOR
Bash Plate (Front):
Yes
Brush Guard:
Yes
Floor Board Location:
Driver
Frame:
Steel
INSTRUMENTATION
Fuel Level Warning Type:
Gauge
LIGHTS
Type:
Halogen
SEATS
Number Of Seats:
1
Seat Height (in):
33.7
Seat Height (mm):
856
Seat Location:
Driver
Seat Material:
Vinyl
Seat Type:
One-Piece
STEERING
Steering Control:
Handlebar
Steering Type:
Manual
STORAGE
Capacity (kgs):
29.9
Capacity (kgs):
60.3
Capacity (lbs):
133
Capacity (lbs):
66
Fender Storage Location:
Front
SUSPENSION
Front Suspension Type:
Independent Double Wishbone
Front Travel (in):
6.7
Front Travel (mm):
170
Number Rear Shock Absorbers:
1
Rear Adjustable Shock / Spring Pre-Load:
Yes
Rear Suspension Material:
Steel
Rear Suspension Type:
Swing Arm
Rear Travel (in):
6.7
Rear Travel (mm):
170
TECHNICAL SPECIFICATIONS
Fuel Capacity (gal):
3.9
Fuel Capacity (l):
14.8
Fuel Capacity Reserve (gal):
1.3
Fuel Capacity Reserve (l):
4.9
Ground Clearance (in):
7.1
Ground Clearance (mm):
180.3
Height (in):
46.2
Height (mm):
1173.5
Length (ft):
6.9
Length (ft/ft):
6
Length (ft/in):
10.8
Length (in):
82.8
Length (mm):
2103.1
Towing Capacity (kgs):
384.7
Towing Capacity (lbs):
848
Turning Radius (ft):
9.2
Wet Weight (kg):
263
Wet Weight (lbs):
580
Wheelbase (in):
50
Wheelbase (mm):
1270
Width (in):
47.4
Width (mm):
1204
TRANSMISSION
Number Of Speeds:
5
Primary Drive (Rear Wheel):
Shaft
Reverse:
Yes
Transmission Type:
Automatic
WHEELS & TIRES
Front Tire (Full Spec):
Maxxis® 24 x 8-12
Front Tire Diameter (in):
24
Front Tire Width:
8
Front Wheel Diameter:
12
Rear Tire (Full Spec):
Maxxis® 24 x 10-11
Rear Tire Diameter (in):
24
Rear Tire Width:
10
Rear Wheel Diameter:
11
Tire Brand:
Maxxis®
Tube / Tubeless:
Tubed
Wheels Composition:
Steel
