Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.17
  • Stroke (in):
    2.19
  • Displacement (cc):
    109.2
  • Carburetion Type:
    Carburetor
  • Turbocharged:
    No
  • Supercharged:
    No
  • Number Of Carburetors:
    1
  • US Miles Per Gallon (Combined):
    110
  • Compression Ratio:
    9.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    No
  • Transmission Brand:
    V-Matic™
  • Primary Drive (Engine / Transmission):
    Belt
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    50.6
  • Fuel Capacity (gal):
    0.9
  • Fuel Capacity Reserve (gal):
    0.2
  • Length (in):
    71.2
  • Width (in):
    29.1
  • Height (in):
    41.1
  • Ground Clearance (in):
    5.8
  • Wet Weight (lbs):
    234
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.1
  • Front Travel (in):
    3.5
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    2.8
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Chromed:
    No
  • Front Tire (Full Spec):
    MRF Zapper: 90/90-12
  • Rear Tire (Full Spec):
    MRF Zapper: 90/100-10
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Drum
  • Front Brake Diameter (in):
    3.7
  • Rear Brake Type:
    Drum
  • Rear Brake Diameter (in):
    3.7
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
