Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.62
  • Stroke (in):
    3.21
  • Displacement (cc):
    1084
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Bore And Stroke:
    92mm x 75mm
  • Induction:
    PGM-FI electronic fuel injection (Throttle By Wire)
  • Ignition:
    Full transistorized ignition
  • Compression Ratio:
    10.1:1
  • Valve Train:
    SOHC; four valves per cylinder
  • Final Drive:
    Chain
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    45mm inverted telescopic fork; 9.9 inches of travel
  • Rear Suspension:
    Pro-Link® system w/ single shock; 9.4 inches of travel
  • Front Brake:
    Two four-piston hydraulic calipers w/ 310mm disks; ABS
  • Rear Brake:
    Single one-piston hydraulic caliper w/ 256mm disk; ABS
  • Front Tire:
    90/90-21
  • Rear Tire:
    150/70R-18
• Dimensions

  add remove
  • Wheelbase:
    62.2 inches
  • Seat Height:
    Standard position 36.2 inches/Low position 35.4 inches
  • Curb Weight:
    555.8 lbs—Includes all standard equipment, required fluids and full tank of fuel—ready to ride
  • Fuel Capacity:
    6.4 gallons including 1.0-gallon reserve
• Other

  add remove
  • Emissions:
    Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.
• Factory Warranty Information

  add remove
  • Warranty:
    Transferable, unlimited-mileage limited warranty
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Gear Ratio (1):
    2.56
  • Gear Ratio (2):
    1.76
  • Gear Ratio (3):
    1.38
  • Gear Ratio (4):
    1.13
  • Gear Ratio (5):
    0.97
  • Gear Ratio (6):
    0.88
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    62
  • Fuel Capacity (gal):
    6.5
  • Fuel Capacity Reserve (gal):
    1
  • Length (in):
    91.7
  • Width (in):
    37.9
  • Height (in):
    60.7
  • Ground Clearance (in):
    9.8
  • Wet Weight (lbs):
    551
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.8
  • Front Travel (in):
    9.9
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    8.7
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Link®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Bridgestone® Battlax Adventurecross Tourer: 90/90 - 21 M/C 54H
  • Rear Tire (Full Spec):
    Bridgestone® Battlax Adventurecross Tourer: 150/70 R18 M/C 70H
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.1
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
