Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.07
  • Stroke (in):
    2.41
  • Displacement (cc):
    292
  • Compression Ratio:
    11.1:1
  • Carburetion Brand:
    Keihin
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Fuel Requirements:
    Regular
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    18.1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    86.6
  • Width (in):
    32.3
  • Height (in):
    47.4
  • Wheelbase (in):
    56.7
  • Ground Clearance (in):
    10.8
  • Wet Weight (lbs):
    302.1
  • Fuel Capacity (gal):
    2.1
  • Towing Capacity (lbs):
    10.8
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    10
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Brand Name:
    UNI-TRAK®
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    9.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Dunlop® D605F: 3.00-21 (51P)
  • Rear Tire (Full Spec):
    Dunlop® D605: 4.60-18 (63P)
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    9.8
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.4
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    35.2
  • Number Of Seats:
    1
