Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.35
  • Stroke (in):
    2.6
  • Displacement (cc):
    749
  • Compression Ratio:
    9.3:1
  • Carburetion Brand:
    Mikuni
  • Carburetion Type:
    Fuel Injected
  • Torque (Ft Lbs):
    42.8
  • Valves Per Cylinder:
    4
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    No
  • Limited Slip Differential Location:
    Front
  • Differential Lock Location:
    Front
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    46.1
  • Height (in):
    47.6
  • Wheelbase (in):
    50.6
  • Ground Clearance (in):
    9
  • Dry Weight (lbs):
    658.8
  • Fuel Capacity (gal):
    5
  • Engine Displacement to Weight (cc):
    1.14
  • Wet Weight (lbs):
    732.1
  • Towing Capacity (lbs):
    1250
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    6.9
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Independent Double Wishbone
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    7.4
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Front Stabilizer Bar:
    No
  • Rear Stabilizer Bar:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    Duro: AT 25 x 8 - 12
  • Rear Tire (Full Spec):
    Duro: AT 25 x 10 - 12
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Sealed Oil Bath Multi-Disc
  • Engine Braking Brand Name:
    K-EBC™
  • Front Brake Diameter (in):
    6.9
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    35.2
  • Number Of Seats:
    1
