Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    61.5
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.62
  • Stroke (in):
    2.96
  • Displacement (cc):
    999
  • Compression Ratio:
    10.1:1
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Engine Brand Name:
    Kawasaki
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Rear Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    Yes
  • Differential Lock Location:
    Rear
  • Limited Slip Differential Location:
    Front
  • Rear Solid Axle:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    64
  • Height (in):
    80.9
  • Wheelbase (in):
    92.3
  • Turning Radius (ft):
    16
  • Ground Clearance (in):
    11.6
  • Dry Weight (lbs):
    1925
  • Payload Capacity (lbs):
    1530.3
  • Towing Capacity (lbs):
    2000
  • Fuel Capacity (gal):
    7.9
  • Engine Displacement to Weight (cc):
    0.52
  • Wet Weight (lbs):
    2008.8
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double Wishbone
  • Rear Suspension Type:
    Independent Double Wishbone
  • Number Rear Shock Absorbers:
    2
  • Air Adjustable:
    No
  • Center Suspension:
    Not Available
  • Front Travel (in):
    11
  • Rear Travel (in):
    10.1
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Duro: 26 x 9-12
  • Rear Tire (Full Spec):
    Duro: 26 x 11-12
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Dual Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Front Brake Diameter (in):
    8.3
  • Rear Brake Diameter (in):
    8.3
• TOWING & HAULING

  add remove
  • Rear Hitch:
    Standard
  • Draw Bar:
    Optional
  • Winch:
    Standard
  • Rear Hitch Type:
    Receiver
  • Size (in):
    2
  • Winch Brand Name:
    Warn®
  • Tilt:
    No
  • Removable Tailgate:
    No
  • Removable Sides:
    No
  • Weight (lbs):
    4500
• STORAGE

  add remove
  • Bed Length (in):
    42.7
  • Bed Width (in):
    53.7
  • Bed Height (in):
    11
  • Cargo Bed Material:
    Steel
  • Bed Capacity (lbs.):
    999
  • Bed Volume (ft3):
    14.6
  • Helmet Storage:
    Not Available
  • Gun Scabbard:
    Optional
  • Number Of Cupholders:
    2
  • Lockable Storage:
    Not Available
  • Cargo Bed Storage:
    Optional
• SEATS

  add remove
  • Seat Type:
    Bench
  • Seat Material:
    Vinyl
  • Number Of Seats:
    6
  • Number Of Rows:
    2
