Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontally Opposed
  • Cylinders:
    6
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    125
  • Torque (Ft Lbs):
    125.4
  • Torque (Nm):
    170
  • Cooling:
    Liquid
  • Valves:
    24
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.87
  • Stroke (in):
    2.87
  • Displacement (cc):
    1833
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression Ratio:
    10.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    7
  • Primary Drive (Rear Wheel):
    Shaft
  • Overdrive:
    Yes
  • Reverse:
    Yes
  • Gear Ratio (1):
    2.17
  • Gear Ratio (2):
    1.69
  • Gear Ratio (3):
    1.3
  • Gear Ratio (4):
    1.04
  • Gear Ratio (5):
    0.82
  • Gear Ratio (6):
    0.66
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    66.9
  • Fuel Capacity (gal):
    5.5
  • Storage Capacity (gal):
    25
  • Length (in):
    102.9
  • Width (in):
    35.6
  • Height (in):
    56.4
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    847
• SUSPENSION

  add remove
  • Front Suspension Type:
    Double-Wishbone
  • Front Travel (in):
    4.3
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    4.1
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Link®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Bridgestone® Exedra G852: 130/70-18 63H
  • Rear Tire (Full Spec):
    Bridgestone® Exedra G853: 200/55 R16 77H
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    12.4
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Brake Brand Name:
    Nissin
