Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.86
  • Stroke (in):
    2.57
  • Displacement (cc):
    271
  • Compression Ratio:
    11.0:1
  • Carburetion Brand:
    Keihin
  • Carburetion Type:
    Carburetor
  • Torque (Ft Lbs):
    15.9
  • Valves Per Cylinder:
    2
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    4X2
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    42.5
  • Height (in):
    46.1
  • Wheelbase (in):
    45.9
  • Ground Clearance (in):
    6.1
  • Fuel Capacity (gal):
    3.2
  • Wet Weight (lbs):
    535.8
  • Towing Capacity (lbs):
    500
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    5.2
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    5.6
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Front Stabilizer Bar:
    No
  • Rear Stabilizer Bar:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Front Tire (Full Spec):
    Maxxis® AT 22 x 7 - 10
  • Rear Tire (Full Spec):
    Maxxis® AT 22 x 10 - 10
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    7.1
  • Rear Brake Diameter (in):
    7.1
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Height (in):
    33.3
  • Number Of Seats:
    1
