Specifications

• Engine

  add remove
  • Cylinders:
    2
  • Horsepower (bhp):
    70
  • Torque (Ft Lbs):
    51
  • Cooling:
    Liquid
  • Displacement (cc):
    800
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    50
  • Height (in):
    57.1
  • Wheelbase (in):
    58
  • Ground Clearance (in):
    11.4
  • Dry Weight (lbs):
    960
  • Fuel Capacity (gal):
    6.9
  • Engine Displacement to Weight (cc):
    0.83
  • Towing Capacity (lbs):
    1800
  • Turning Radius (ft):
    10.9
• SUSPENSION

  add remove
  • Rear Suspension Type:
    Independent A-Arm
  • Number Rear Shock Absorbers:
    2
  • Front Travel (in):
    9
  • Rear Travel (in):
    9
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    26
  • Rear Tire Diameter (in):
    26
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    CST 26 x 8 R14
  • Rear Tire (Full Spec):
    CST 26 x 10 R14
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
