Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valve Configuration:
    SOHC
  • Bore (in):
    1.54
  • Stroke (in):
    1.63
  • Displacement (cc):
    49
  • Carburetion Type:
    Carburetor
  • Parental Controls:
    Standard
  • Valves Per Cylinder:
    2
  • Speed Governor:
    Yes
  • Compression Ratio:
    8.5:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Number Of Speeds:
    1
  • Hi / Low Range:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• DRIVE LINE

  add remove
  • Driveline Type:
    4X2
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    32.3
  • Height (in):
    30.3
  • Wheelbase (in):
    32.7
  • Ground Clearance (in):
    3.5
  • Fuel Capacity (gal):
    1.5
  • Engine Displacement to Weight (cc):
    0.22
  • Wet Weight (lbs):
    220
• SUSPENSION

  add remove
  • Front Suspension Type:
    A-Arm
  • Front Travel (in):
    2.4
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Swing Arm
  • Rear Travel (in):
    2
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Tube / Tubeless:
    Tubeless
  • Front Tire Diameter (in):
    16
  • Rear Tire Diameter (in):
    16
  • Front Tire (Full Spec):
    Duro® AT 16 X 6.5-7
  • Rear Tire (Full Spec):
    Duro® AT 16 X 7-7
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Sealed Drum
  • Rear Brake Type:
    Sealed Drum
