Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.74
  • Stroke (in):
    2.5
  • Displacement (cc):
    449
  • Carburetion Type:
    Fuel Injected
  • Valves Per Cylinder:
    5
  • Fuel Injector Size (mm):
    42
  • Compression Ratio:
    11.8:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Hi / Low Range:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• DRIVE LINE

  add remove
  • Driveline Type:
    4X2
  • Number Of Driveline Modes:
    1
  • Rear Unlocking Differential:
    No
  • Rear Solid Axle:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    48.8
  • Height (in):
    41.9
  • Wheelbase (in):
    50
  • Ground Clearance (in):
    9.3
  • Fuel Capacity (gal):
    2.6
  • Engine Displacement to Weight (cc):
    1.11
  • Wet Weight (lbs):
    405
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    9.8
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Swing Arm
  • Rear Travel (in):
    11
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Size (in):
    1.8
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Tube / Tubeless:
    Tubeless
  • Front Tire Diameter (in):
    21
  • Rear Tire Diameter (in):
    20
  • Front Tire (Full Spec):
    Maxxis® AT 21 X 7-10
  • Rear Tire (Full Spec):
    Maxxis® AT 20 X 10-9
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    6.3
  • Rear Brake Diameter (in):
    7.9
